VIA polyamide standard

  • Robust polyamide handset
  • Auto-start function via reed contact
  • Magnetic wall mount with cable outlet



283.00

delivery time: on stock

Product Description

This VIA handset is made from glass-fibre-reinforced polyamide as standard. The casing is exceptionally robust, sits comfortably and securely in the hand thanks to its conical shape, and is easy to clean.

The VIA handset is held on its base by a strong magnet. When the handset is removed from the base, reed contact is activated and the audio starts playing automatically. When the handset is placed back on its base, playback stops. Buttons or rocker switches can be integrated into the casing cover, allowing the user to switch between two languages or navigate through a menu. These options can be labelled with either engravings or stickers on the casing cover.

We manufacture the handsets in the colours black, basalt grey, telegrey and white. Customisation is possible in virtually all RAL Classic colours.

A robust, flexible stainless-steel tube protects the connection cable and reliably secures the handset.

Delivery includes

VIA handset, magnetic wall mount with cable outlet at 90° angle (parallel to mounting surface), mounting screw for wall mount (M4), installation instructions

Technical Data

Handset:
Height: 56 mm
Ø: 60 mm
Weight (without mount and protective tube): 140 g

Cable:
Connection cable: Length: 240 cm, Ø: 6 mm
Flexible stainless-steel tube: Length: 125 cm, Ø: 8 mm

Mount:
Height: 30 mm
Ø: 52 mm

Speaker:
Impedance: 32 Ω
Max. loading capacity: 0.1 W

Sensor:
Switching capacity: 10 W
Max. switching voltage: 175 V (AC/DC)
Switching current: 0.5 A

Produkt Advisory

We recommend an installation height of at least 130 cm to avoid damage to both the handset and the floor.

Accessories

VIA/USO Language Selection Switch

The language selection switch in black plastic can be ordered as an option for the VIA and USO handsets. It is used to switch between two languages or audio tracks.

Special-length USO/VIA metal protective tubing

Special-length stainless steel metal protective tubing. Only possible together with purchase orders of USO/VIA.

Klinkenstecker für Einhandhörer
USO/VIA/PLUX Jack Plug

Preassembled connection cable with audio jack plug. Only possible together with purchase orders of USO/VIA/PLUX. Connector: 3.5 mm jack plug.
